Square Legs – Center Mount

Part Number	Column Size	Diameter	Plate Size	Recommended Max Top Depth	Base Spread	Top Size	Length	Stretcher Length	Recommended Table Length	Overall Height	Side Panels	Use With Panel Base Part	Style	Panel Shape	Recommended Top Size	Weight
2514	2" sq															7 lbs.
3030	3" sq															12 lbs.

Construction: Welded
Column: 14ga Tube
Mounting Plate:
- Center mounted on a 6″ x 6″ steel plate
- Requires (8) #12-14 screws (not supplied)
Base Height: 27-3/4″
Adjustable Leveler: 3/8-16 x 1-3/4″ long shank, black
Finish: Powder coat finish as standard.
Assembly and Shipping:
- No assembly required
- Parts ship 1 per box
- Can be shipped via FedEx or UPS

Unfinished/Raw: subtract $4 LIST
Polished or Satin Chrome:
- Standard height:
  - #2514, add $235 LIST
  - #3030, add $265 LIST
- Taller, up to bar height:
  - #2514, add $270 LIST
  - #3030, add $315 LIST
Special Heights:
- Shorter, add $20 LIST
- Taller up to Bar Height:
  - #2514 add $38 LIST
  - #3030 add $70 LIST
- Bar Height (40.75″), add prefix “B” to part #:
  - #2514 add $38 LIST
  - #3030 add $70 LIST
Casters:
- Hard Wheel: add prefix “C” to part #
  - #2514 add $18 LIST (60mm)
  - #3030 add $26 LIST (75mm)
- Soft Wheel: Add prefix “D” to part #
  - #2514 add $21 LIST (60mm)
    - Only available on 2″ leg

List quantity, part #, description, finish, and price.
All prices are FOB our facility, please specify your preferred method of shipment
Specify shipping and billing address
Please read terms and warranty

Square Leg – Center Mount – Spec Sheet

The center mount square leg offers an inspiring, high-end look. Gibraltar offers both a 2″ and 3″ square leg with an adjustable leveler. Custom heights are easily manufactured. Available in a powder coat finish, this leg is sure to add an element of distinction to your table.
