Square Legs - Corner Mount

The corner mount square leg offers an opportunity to mount the leg flush with the corner of the table top for an inspiring, high-end look. Gibraltar offers both a 2″ and 3″ square leg with an adjustable leveler. Custom heights are easily manufactured. Available in powder coat, polished chrome, and satin chrome, this leg is sure to add an element of distinction to your table.

ADDITIONAL SURCHARGE EFFECTIVE AUGUST 2, 2021

#2510  –  8%

#3510  –  22%

Part #Column SizeRecommended Max. Top DepthBase SpreadLengthWeightOverall Height
25102" sqN/AN/AN/A8 lbs.27-3/4"
35103" sqN/AN/AN/A13 lbs.27-3/4"
  • Construction: Welded
  • Column: 14ga Tube
  • Mounting Plate:
    • Corner mounted on a 4″ x 4″ x 5/16″ steel plate
    • Requires (8) #12-14 screws, not supplied
  • Base Height: 27-3/4″
  • Adjustable Leveler: 3/8-16 x 1-3/4″ long shank, black
  • Finish: Powder coat finish as standard.
  • Assembly and Shipping:
    • No assembly required
    • Parts ship 1 per box
    • Can be shipped via FedEx or UPS
  • Unfinished/Raw: subtract $4.14 LIST
  • Polished or Satin Chrome:
    • Standard Height:
      • #2510 add $37.26 LIST
      • #3510 add $55.89 LIST
    • Taller, up to Bar Height
      • #2510 add $49.68 LIST
      • #3510 add $78.66 LIST
  • Special heights:
    • Shorter, add $20.70 LIST
    • Taller up to Bar Height same as Bar Height pricing below…
    • Bar Height (40-3/4″), add prefix “B” to part #
      • #2510 add $41.40 LIST
      • #3510 add $46.58
  • Casters:
    • Hard Wheel: Add prefix “C” to part #
      • #2510 add $14.49 LIST (60mm)
      • #3510 add $18.63 LIST (75mm)
    • Soft Wheel:
      • Add prefix “D” to part #
      • #2510 add $21.74 LIST (60mm)
      • #3510 add $41.74 LIST (75mm)
  • Wire Holes
    • Available, please call to discuss
  • List quantity, part #, description, finish, and price.
  • All prices are FOB our facility, please specify your preferred method of shipment
  • Specify shipping and billing address
  • Please read terms and warranty
