Square and Rectangle Pedestal Base

When you need to maximize the space under a table, pedestal bases are an excellent choice. These low profile discs almost make the base disappear into the floor while still maintaining the stability and mobility needed in a freestanding table. Our standard style has no levelers and it sits flat on the floor almost undetected by your feet. Levelers are offered as an option, and position the base about 1″ off the floor.



Part #Column SizeRecommended Max. Top DepthBase SpreadLengthWeightOverall HeightSide PanelsPanel ShapePanel StyleRecommended Top Size
18704"36" sq18" sq39 lbs.27-3/4"
18714"42" sq23-3/4" sq56 lbs.27-3/4"
18726"48" sq23-3/4" sq60 lbs.27-3/4"
18756"36" x 60"18" x 28"55 lbs.27-3/4"
18766"42" x 60"24" x 28"66 lbs.27-3/4"
  • Construction:
    • Mounting plate welded to column
    • Discs are bolted to column assembly with (2) flat head screws (provided).
  • Column:
    • #1870 and #1871 use a 4″ diameter, 16 ga tube
    • #1872, #1875, and #1876 use a 6″ diameter, 16ga tube
  • Discs: 1/4″ steel
  • Mounting Plate:
    • 12″ x 12″ steel plate
    • Requires (12) #12-14 screws, not supplied
  • Base Height: 27-3/4″
  • Adjustable Leveler (optional):
    • 1/4-20 x 1/2″ long shank, black. See Options
  • Finish: Powder coat finish as standard.
  • Assembly and Shipping:
    • Shipped KD, assembly required
    • Parts in 2 separate boxes (column assembly in one, disc in another)
    • Can be shipped via FedEx or UPS
  • Unfinished/Raw: subtract $15 LIST
  • Special Heights:
    • Shorter, add $28 LIST
    • Taller up to bar height:
      • #1870 and #1871 add $59 LIST
      • #1872, #1875, and #1876 add $105 LIST
    • Bar Height, add prefix “B” to part #:
      • #1870 and #1871 add $59 LIST
      • #1872, #1875, and #1876 add $105 LIST
  • Levelers:
    • Add prefix “L” to part #, add $32 LIST
    • Levelers are suggested for all uneven surfaces
  • Flip Top:
    • Add prefix “FT” to part #, add $148 LIST
    • Max. top size supported is 54″
  • Internal Wire Access:
    • Add prefix “W” to part #, add $85 LIST
    • Includes 3.5″ hole through mounting plate & 1.4″ hole out bottom of disc
    • Highly recommend combining with the Leveler option
  • Power Box Wire Management (for larger power applications):
    • Add prefix “W” to part # and suffix “-0005” (ex: LW1844-0005), add $218 LIST
    • A steel box mounting plate with a 9.6″ x 9.6″ x 2.75″ tall I.D. allows room for a power module to be concealed. Wires and plugs travel the inside of the column and out a 1.4″ hole out bottom of disc. Box is powder coated to match base.
    • Highly recommend combining with the Leveler option
  • List quantity, part #, description, finish, and price.
  • All prices are FOB our facility, please specify your preferred method of shipment
  • Specify shipping and billing address
  • Please read terms and warranty

Square & Rectangle Pedestal Base – Spec Sheet
