Name: Round Pedestal Base
SKU: 1844P
Price: 464 USD
Availability: instock

Construction:
- Mounting plate welded to column
- Discs are bolted to column assembly with (2) flat head screws (provided).
Column:
- #1844, #2244, and #2266 use 4″ diameter, 16 ga tube
- #2267 uses a 6″ diameter, 16ga tube
Discs: 1/4″ steel
Mounting Plate:
- 12″ x 12″ steel plate
- Requires (12) #12-14 screws, not supplied
Base Height: 27-3/4″
Adjustable Leveler (optional):
- 1/4-20 x 1/2″ long shank, black. See Options
Finish: Powder coat finish as standard.
Assembly and Shipping:
- Shipped KD, assembly required
- Parts in 2 separate boxes (column assembly in one, disc in another)
- Can be shipped via FedEx or UPS

Unfinished/Raw: subtract $15 LIST
Polished or Satin Chrome:
- Standard height:
  - Part 1844, add $510 LIST
  - Part 2244, add $590 LIST
  - Part 2266, add $785 LIST
- Taller, up to and including bar height:
  - Part 1844, add $585 LIST
  - Part 2244, add $665 LIST
  - Part 2266, add $860 LIST
- Part 2267 – N/A
- Special Height Surcharge of $75 LIST per base when ordering less than 6 (only applies to chrome finish)
Special Heights:
- Shorter, add $25 LIST
- Taller up to bar height:
  - 1844, 2244, & 2266, add $59 LIST
  - 2267, add $105 LIST
- Bar Height, add prefix “B” to part #:
  - 1844, 2244, & 2266, add $59 LIST
  - 2267, add $105 LIST
Levelers:
- Add prefix “L” to part #, add $32 LIST
- Levelers are suggested for all uneven surfaces
Flip Top:
- Add prefix “FT” to part #, add $148 LIST
- Max. top size supported is 54″
Internal Wire Access:
- Add prefix “W” to part #, add $85 LIST
- Includes 3.5″ hole through the mounting plate and 1.4″ hole out bottom of disc.
- Highly recommend combining with the Leveler option
Power Box Wire Management:
- Add prefix “W” to part # and suffix “-0005” (ex: LW1844-0005), add $218 LIST
- A steel box mounting plate with a 9.6″ x 9.6″ x 2.75″ tall I.D. allows room for a powder module to be concealed. Wires and plugs travel down the inside of the column and out a 1.4″ hole out bottom of disc. Box is powder coated to match base.
- Highly recommend combining with the Leveler option

List quantity, part #, description, finish, and price.
All prices are FOB our facility. Please specify your preferred method of shipment
Specify shipping and billing address
Please read terms and warranty

Part #	Column Size	Recommended Max. Top Depth	Base Spread	Weight	Overall Height
1844	4"	36" rd	18" rd	31 lbs.	27-3/4"
2244	4"	42" rd	23-3/4" rd	45 lbs.	27-3/4"
2266	4"	54" rd	28" rd	50 lbs.	27-3/4"
2267	6"	60" rd	32" rd	75 lbs.	27-3/4"
