Propel T Base

The Propel T base brings a great new look to tables. The Propel series offers a steel column with cast aluminum feet, and can be finished in powder coat, polished aluminum/chrome, satin aluminum/satin chrome, or a combination of powder coat/polished or satin finishes. Patented base.

ADDITIONAL 15% SURCHARGE EFFECTIVE AUGUST 2, 2021

Part #Column SizeRecommended Max. Top DepthBase SpreadLengthWeightOverall Height
55802-1/4"20"15-1/4"N/A10 lbs.27-3/4"
55842-1/4"26"20"N/A11 lbs.27-3/4"
55882-1/4"36"26"N/A11 lbs.27-3/4"
55902-1/4"42"32-3/4"N/A12 lbs.27-3/4"
55922-1/4"48"38-1/4"N/A20 lbs.27-3/4"
  • Construction: Bolted, welded combination
  • Tubing: 2-1/4″ OD x 13ga tubing
  • Base: Cast aluminum
  • Mounting Plate:
    • #5580, #5584, and #5588 use a 6″ x 8″ plate.?? Requires (8) #12-14 screws (not supplied)
    • #5590 uses an 8″ x 8″ plate. Requires (12) #12-14 screws (not supplied)
    • #5592 uses a 12″ x 12″ plate. Requires (12) #12-14 screws (not supplied)
  • Base Height: 27-3/4″
  • Adjustable Leveler: 3/8-16 x 3/4″ long shank.
  • Finish:
    • Powder coat finish as standard.
    • Polish and Satin options are a combination of chrome (column) and aluminum (feet)
  • Assembly and Shipping:
    • Parts #5580, #5584, and #5588 ship assembled.
    • Parts #5590 and #5592 ship KD, assembly of feet required
    • Parts #5580, #5584, #5588, and #5590 ship 2 per box (sold individually).
      • Broken carton charge for odd quantity is $20.70 LIST
    • Part #5092 ships 1 per box
    • Can be shipped via FedEx or UPS
  • Unfinished/Raw: subtract $6.21 LIST
  • Polished Chrome:
    • #5580, #5584, and #5588 add $31.05 LIST
    • #5590 and #5592 add $33.12 LIST
  • Special Heights:
    • Shorter, add $25.88 LIST
    • Taller up to bar height, add $36.23 LIST
    • Bar Height, add prefix “B” to part #, add $36.23 LIST
  • Casters:
    • Hard Wheel: Add prefix “C” to part #, add $14.49 LIST
    • Soft Wheel: Add prefix “D” to part #, add $21.74 LIST
  • Self-Leveling Glides:
    • Add prefix “K” to part #, add $36.23 LIST
    • Self-Leveling glides do add to base height
  • Adjustable Spring Clip:
    • Height range 24-3/4″ – 33-3/4″ add prefix “AH” to part #, add $70.38 LIST
    • Height range 27-3/4″ – 40-3/4″ add prefix “AHB” to part #, add $101.43 LIST
  • Wire Holes
    • Add prefix “W” to part #, add $20.70 LIST
    • Includes (2) wire holes with 1-1/4″ removable grommets.
    • Holes are 1-1/2″ x 2-1/4″ with grommets removed.
  • List quantity, part #, description, finish, and price.
  • All prices are FOB our facility, please specify your preferred method of shipment
  • Specify shipping and billing address
  • Please read terms and warranty
