Name: Propel X Base - Round/Square Application
SKU: 5720P
Price: 226 USD
Availability: instock

Construction: Bolted, welded combination
Tubing: 2-1/4″ OD x 13ga tubing
Base: Cast aluminum
Mounting Plate:
- #5720, #5726, and #5733 use an 8″ x 8″ steel plate. Requires (12) #12-14 screws (not supplied)
- #5738 uses a 12″ x 12″ plate. Requires (12) #12-14 screws (not supplied)
Base Height: 27-3/4″
Adjustable Leveler: 3/8-16 x 3/4″ long shank.
Finish:
- Powder coat finish as standard.
- Polish and Satin options are a combination of chrome (column) and aluminum (feet)
Assembly and Shipping:
- Parts ship KD, assembly of feet required
- Parts ship 1 per box
- Can be shipped via FedEx or UPS

Unfinished/Raw: subtract $10 LIST
Polished Chrome:
- Standard height, add $76 LIST
- Taller, up to bar height, add $86 LIST
Special heights:
- Shorter, add $25 LIST
- Taller up to bar height, add $35 LIST
- Bar Height, add prefix “B” to part #, add $35 LIST
Casters:
- Hard Wheel: Add prefix “C” to part #, add $32 LIST
- Soft Wheel: Add prefix “D” to part #, add $46 LIST

Self-Leveling Glides:
- Add prefix “K” to part #, add $33 LIST
- Self-Leveling glides do add approx. 1/2″ to base height
Flip-Top
- Add prefix “FT” to part #, add $136 LIST
- Max Top is 46″ with casters
Adjustable Spring Clip:
- Height range 24-3/4″ – 33-3/4″ add prefix “AH” to part #, add $124 LIST
- Height range 27-3/4″ – 40-3/4″ add prefix “AHB” to part #, add $144 LIST
Power Cone/Wire Management
- Add prefix “W” to part #, add $155 LIST
- Includes a steel cone-shaped mounting plate: tapers from 10-1/2″ – 3″.
- (1) wire hole at bottom of column with removable grommet.
- Wire hole is 1-1/2″ x 2-1/4″ with grommet removed, grommet has 1-1/4″ hole in it.
Power Box /Wire Management (for larger power applications)
- Add prefix “W” to part # and suffix “-0005” (ex: W5726-0005), add $177 LIST
- Includes a steel box mounting plate: 9-5/8″ x 9-5/8″ x 2-3/4″ tall
- (1) wire hole at bottom of column with removable grommet.
- Wire hole is 1-1/2″ x 2-1/4″ with grommet removed, grommet has 1-1/4″ hole in it.

List quantity, part #, description, finish, and price.
All prices are FOB our facility, please specify your preferred method of shipment
Specify shipping and billing address
Please read terms and warranty

Part #	Column Size	Recommended Max. Top Depth	Base Spread	Length	Weight	Overall Height
5720	2-1/4"	24"rd	20" x 20"	N/A	14 lbs.	27-3/4"
5726	2-1/4"	36"rd	26" x 26"	N/A	15 lbs.	27-3/4"
5733	2-1/4"	42"rd	32-3/4" x 32-3/4"	N/A	16 lbs.	27-3/4"
5738	2-1/4"	54"rd	38-1/4" x 38-1/4"	N/A	23 lbs.	27-3/4"

Propel X Base – Round/Square Application
