DuraCast T Base

The DuraCast T base brings a great new look to tables. The DuraCast series offers a steel column with cast aluminum feet, and can be finished in powder coat, polished aluminum/chrome, satin aluminum/satin chrome, or a combination of powder coat/polished or satin finishes. Patented base.



Part #Column SizeRecommended Max. Top DepthBase SpreadLengthWeightOverall HeightSide PanelsPanel ShapePanel StyleRecommended Top Size
50802-1/4" Dia.20"15-1/4"10 lbs.27-3/4"
50842-1/4" Dia.26"20"11 lbs.27-3/4"
50882-1/4" Dia.36"26"11 lbs.27-3/4"
50902-1/4" Dia.42"33-1/4"12 lbs.27-3/4"
50922-1/4" Dia.48"38-1/4"20 lbs.27-3/4"
  • Construction: Bolted, welded combination
  • Tubing: 2-1/4″ OD x 13ga tubing
  • Base: Cast aluminum
  • Mounting Plate:
    • #5080, #5084, and #5088 use a 6″ x 8″ plate. Requires (6-8) #12-14 screws (not supplied)
    • #5090 uses an 8″ x 8″ plate. Requires (10-12) #12-14 screws (not supplied)
    • #5092 uses a 12″ x 12″ plate. Requires (12) #12-14 screws (not supplied)
  • Base Height: 27-3/4″
  • Adjustable Leveler: 3/8-16 x 3/4″ long shank.
  • Finish: Powder coat finish as standard.
    • Polished and Satin options are a combination of chrome (column) and aluminum (feet)
  • Assembly and Shipping:
    • Parts #5080, #5084, and #5088 ship assembled.
    • Parts #5090 and #5092 ship KD, assembly of feet required
    • Parts #5080, #5084, #5088, and #5090 ship 2 per box (sold individually).
    • Broken carton charge for odd quantity is $20 LIST
    • Part #5092 ships 1 per box
    • Can be shipped via FedEx or UPS
  • Unfinished/Raw: subtract $6 LIST
  • Polished or Satin Chrome:
    • Standard height, add $205 LIST
    • Taller, up to bar height, add $260 LIST
    • For Chrome on AH & AHB options, add $365 LIST
  • Special heights:
    • Shorter, add $28 LIST
    • Taller up to bar height, add $38 LIST
    • Bar Height, add prefix “B” to part #, add $38 LIST
  • Casters:
    • Hard Wheel: Add prefix “C” to part #, add $17 LIST
    • Soft Wheel: Add prefix “D” to part #, add $24 LIST
  • Self-Leveling Glides:
    • Add prefix “K” to part #, add $20 LIST
    • Self-Leveling glides do add approx. 1/2″ to base height
  • Leveler Extensions:
    • Add prefix “E” to part #, add $30 LIST
    • Used in combination with casters for wheelbarrow application.
  • Adjustable Spring Clip:
    • Height range 24-3/4″ – 33-3/4″ add prefix “AH” to part #, add $78 LIST
    • Height range 27-3/4″ – 40-3/4″ add prefix “AHB” to part #, add $98 LIST
  • Wire Holes:

    • Add prefix “W” to part #, add $28 LIST
    • Includes (2) wire holes with 1-1/4″ removable grommets.
    • Holes are 1-1/2″ x 2-1/4″ with grommets removed.
  • List quantity, part #, description, finish, and price.
  • All prices are FOB our facility, please specify your preferred method of shipment
  • Specify shipping and billing address
  • Please read terms and warranty

DuraCast T Base – Spec Sheet
