Round Legs

When you need a top quality, cost sensitive post leg, Gibraltar offers custom lengths and a wide range of diameters to choose from. This back-to-basics offering fits in most any budget.



Contact Us for Pricing
Part #Column SizeRecommended Max. Top DepthBase SpreadLengthWeightOverall HeightSide PanelsPanel ShapePanel StyleRecommended Top Size
15001-1/2"7 lbs.27-3/4"
20002"6 lbs.27-3/4"
30003"8 lbs.27-3/4"
40004"9 lbs.27-3/4"
60006"10 lbs.27-3/4"
  • Construction: Welded
  • Tubing:
    • 1-1/2″ and 2″ tube is 14 ga
    • 3″, 4″, and 6″ tube is 16 ga
  • Mounting Plate:
    • 1.5″, 2″, 3″, and 4″ use a 6″ x 6″ x .125″ steel plate
      • Requires (4-8) #12-14 screws, not supplied
    • 6″ uses a 8″ x 8″ x .187″ steel plate
      • Requires (4-8) #12-14 screws, not supplied
  • Base Height: 27-3/4″
  • Adjustable Leveler:
    • 2″ tubes have a 1/4-20 x 1-3/4″ long shank
    • 1.5″, 3″, 4″, and 6″ tubes have a 3/8-16 x 1-3/4″ long shank
  • Finish: Powder coat finish as standard.
  • Assembly and Shipping:
    • Parts ship fully welded
    • Part #1500 ships 2 per box (sold individually)
      • Broken carton charge for odd quantity is $20 LIST
    • #2000, #3000, #4000, and #6000 ship 1 per box
    • Can be shipped via FedEx or UPS
  • Unfinished/Raw: subtract $4 LIST
  • Polished or Satin Chrome:
    • Standard height:
      • 1.5″ Leg, add $235 LIST
      • 2″ Leg, add $235 LIST
      • 3″ Leg, add $250 LIST
      • 4″ Leg, add $280 LIST
      • 6″ Leg, add $295 LIST
    • Taller, up to and including bar height:
      • 2″ Leg, add $305 LIST
      • 3″ Leg, add $305 LIST
      • 4″ Leg, add $365 LIST
      • 6″ Leg, add $380 LIST
    • For Chrome on AH & AHB options (2″), add $365 LIST
  • Special heights:
    • Shorter, add $24 LIST
    • Taller up to and including Bar Height (40-3/4″):
      • 2″ Leg, add $28 LIST
      • 3″ Leg, add $38 LIST
      • 4″ Leg, add $46 LIST
      • 6″ Leg, add $115 LIST
  • Casters:
    • Hard Wheel: Add prefix “C” to part #:
      • 1.5″ Leg, add $12 LIST (50mm)
      • 2″ Leg, add $10 LIST (60mm)
      • 3″ Leg, add $20 LIST (75mm)
      • 4″ Leg, add $26 LIST (100mm)
      • 6″ Leg, N/A
    • Soft Wheel: Add prefix “D” to part #:
      • 2″ Leg, add #21 LIST (60mm)
        • Only available on 2″ Leg
  • Self-Leveling Glide:
    • Add prefix “K” to part #, add $16 LIST
    • Self-Leveling Glides do add approx. 3/4″ to base height
  • Adjustable Spring Clip (only available on part 2000):
    • Height range 24-3/4″ – 33-3/4″: add prefix “AH” to part #, add $72 LIST
    • Height range 27-3/4″ – 40-3/4″: add prefix “AHB” to part #, add $98 LIST
  • Folding (only available on part 2000):
    • Folding Mechanism: Add prefix “F” to part #, add $124 LIST
      • Maximum top size is 36″ x 60″ or 48″ x 48″
    • Heavy Duty Folding Mechanism: Add prefix “HDF” to part #, add $140 LIST
      • For tops larger than 36″ x 60″, 48″ x 48″ or heavy-duty application on smaller tables
  • List quantity, part #, description, finish, and price.
  • All prices are FOB our facility, please specify your preferred method of shipment
  • Specify shipping and billing address
  • Please read terms and warranty

Round Straight Leg – Spec Sheet
